INSTALLATION
7
STEP 2 – Setup the
CapTel
For Desktop Use
1. Plug the AC adapter cord into the round
power jack on the bottom of the CapTel.
2. Plug the telephone line cord into
the first (left) telephone line jack.
3. Attach the desktop/wall footplate,
making sure the larger side is along
the top edge of the CapTel.
4. Plug the telephone line cord into the
wall jack and the AC adapter into an
electrical outlet.
For Mounting on Wall
To mount the CapTel on a wall, follow the
above instructions with the following changes:
1. Flip the handset hook over so
that the hook points up.
2. Plug the 6-inch telephone line cord
into the telephone jack.
3. Attach the desktop/wall footplate,
making sure the larger side is down.
4. Plug the telephone cord into
the wall jack. Then, line up
the holes in the desktop/wall footplate
with the studs on the wall. Hook the
footplate on the studs and pull down.
NOTE: To personalize the menu settings after setup, see pages 19-24.
To setup CapTel with other devices (such as a signaler or
answering machine) see page 46.
To setup CapTel for 2-Line Mode see page 32.
