DVP-ES2/SX2/SS2/SA2/SX2/SE Operation Manual – Programming
3-474
API Mnemonic Operands Function
266
D
BOUT
Output Specified Bit of a Word
Controllers
ES2/EX2 SS2 SA2
SE
SX2
Bit Devices Word devices Program Steps
Type
OP
X Y M S K H KnX KnY KnM KnS T C D E F
D
* * * * * *
n * * * * * * * * ***
BOUT: 5 steps
DBOUT: 9 steps
PULSE 16-bit 32-bit
ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2
Operands:
D: Destination output device n: Device specifying the output bit
Explanations:
1. For ES2/EX2 models, only V1.20 or above supports the function.
2. Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
3. BOUT instruction performs bit output on the output device according to the value specified by
operand n.
Status of Coils and Associated Contacts:
BOUT instruction
Associated Contacts
Evaluation result
Coil
NO contact（normally open） NC contact（normally closed）
FALSE OFF Current blocked Current flows
TRUE ON Current flows Current blocked
Program Example:
X0 X1
BOUT K4Y0 D0
Instruction: Operation:
LDI X0 Load NC contact X0
AND X1 Connect NO contact
X1 in series.
BOUT K4Y0 D0 When D0 = k1,
executes output on Y1
When D0 = k2,
executes output on Y2
