186 Voice API for Windows Operating Systems Library Reference — November 2003
dx_deltones( ) — delete all user-defined tones
dx_deltones( )
delete all user-defined tones
!
!!
! Description
The dx_deltones( ) function deletes all user-defined tones previously added to a channel with
dx_addtone( ). If no user-defined tones were previously enabled for this channel, this function has
no effect.
Note: Calling this function deletes ALL user-defined tones set by dx_blddt( ), dx_bldst( ),
dx_bldstcad( ), or dx_blddtcad( ).
!
!!
! Cautions
When using this function in a multi-threaded application, use critical sections or a semaphore
around the function call to ensure a thread-safe application. Failure to do so will result in “Bad
Tone Template ID” errors.
!
!!
! Errors
If the function returns -1, use the Standard Runtime Library (SRL) Standard Attribute function
ATDV_LASTERR( ) to obtain the error code or use ATDV_ERRMSGP( ) to obtain a descriptive
error message. One of the following error codes may be returned:
EDX_BADPARM
Invalid parameter
EDX_BADPROD
Function not supported on this board
EDX_SYSTEM
Error from operating system; use dx_fileerrno( ) to obtain error value
Name: int dx_deltones(chdev)
Inputs: int chdev
• valid channel device handle
Returns: 0 if successful
-1 if error
Includes: srllib.h
dxxxlib.h
Category: Global Tone Detection
Mode: synchronous
Platform: DM3, Springware
Parameter Description
chdev specifies the valid channel device handle obtained when the channel was opened
using dx_open( )
