Voice API for Windows Operating Systems Library Reference — November 2003 177
clear all fields in a DV_TPT structure — dx_clrtpt( )
dx_clrtpt( )
clear all fields in a DV_TPT structure
!
!!
! Description
The dx_clrtpt( ) function clears all fields except tp_type and tp_nextp in the specified number of
DV_TPT structures. This function is provided as a convenient way of clearing a DV_TPT
structure, before reinitializing it for a new set of termination conditions.
Notes: 1. The DV_TPT is defined in srllib.h rather than dxxxlib.h since it can be used by other non-voice
devices.
2. Before calling dx_clrtpt( ), you must set the tp_type field of DV_TPT as follows:
IO_CONT if the next DV_TPT is contiguous
IO_LINK if the next DV_TPT is linked
IO_EOT for the last DV_TPT
!
!!
! Cautions
If tp_type in the DV_TPT structure is set to IO_LINK, you must set tp_nextp to point to the next
DV_TPT in the chain. The last DV_TPT in the chain must have its tp_type field set to IO_EOT. By
setting the tp_type and tp_nextp fields appropriately, dx_clrtpt( ) can be used to clear a
combination of contiguous and linked DV_TPT structures.
To reinitialize DV_TPT structures with a new set of conditions, call dx_clrtpt( ) only after the
links have been set up properly, as illustrated in the Example.
Name: int dx_clrtpt(tptp, size)
Inputs: DV_TPT *tptp
• pointer to Termination Parameter Table structure
int size
• number of entries to clear
Returns: 0 if success
-1 if failure
Includes: srllib.h
dxxxlib.h
Category: Structure Clearance
Mode: synchronous
Platform: DM3, Springware
Parameter Description
tptp points to the first DV_TPT structure to be cleared
size indicates the number of DV_TPT structures to clear. If size is set to 0, the
function will return a 0 to indicate success. For more information on this
structure, see DV_TPT, on page 485.
