5330/5340 IP Phones – User Guide
91
Feature Function
Out of range Repetitive 3-pitch tone until you are back in range.
Note: If you are out of range for more than 10 seconds,
any call that is in progress is dropped and not
recovered.
Cordless Headset LEDs
There are two LEDs associated with the cordless headset:
• A blue LED on the headset indicates the headset status
• A green LED in the headset charging cradle indicates battery status
LED Color LED
State
Indicates
Solid Headset mic is muted
Blinking Headset is in pairing mode
Winking Active audio path between Headset and Module
Solid for 2
seconds
• Pairing successful OR
• New battery installed
Blue
(on headset)
Off • No audio path between Headset and Module OR
• Battery is dead
Solid Battery is fully charged
Blinking Battery is charging. Note: It is normal for the headset LED to
cycle between blinking and solid as battery charge is
maintained.
Winking Indicates low voltage when headset is uncradled
Green
(on cradle)
Off When headset is cradled, indicates battery is not charging.
Blinking: LED is On and Off for equal amount of time
Winking: LED is On for a short period of time and Off for a longer period
