PC Programming Manual References
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600 only)—Supplementary
Service— COLP, CLIR, COLR, CNIP, CONP, CNIR, CONR, CF (Rerouting), CT, CCBS, E911
3.35 [1-3] Option— New Card Installation—ISDN Standard Mode for PRI23 Card (KX-TDA100/
KX-TDA200/KX-TDA600 only)
Operating Manual References
1.3.29 FWD (Call Forwarding)
13.1.21 Private Network Features—QSIG—CLIP/COLP (Calling/
Connected Line Identification Presentation) and CNIP/CONP
(Calling/Connected Name Identification Presentation)
Description
Calling Line Identification Presentation (CLIP) and Calling Name Identification Presentation
(CNIP):
The
PBX can send a preprogrammed extension number and/or name to the QSIG network when an extension
user makes a call. The called party can see the number and/or name on his telephone display before answering
the call.
Connected Line Identification Presentation (COLP) and Connected Name Identification
Presentation (CONP):
The PBX sends a preprogrammed extension number and/or name to the QSIG network when the extension
user answers an incoming call. The caller can see the number and/or name of the answering party on his
telephone display when the call is answered.
[CLIP/CNIP Example]
1) Dials "202".
2) "John
101"
is displayed.
PBX-1 PBX-2
CLIP: 101
CNIP: John
Called party
(Extn. No.: 202)
Caller
(Extn. No.: 101
Extn. Name: John)
Document Version 2008-11 Feature Manual 257
13.1.21 Private Network Features—
QSIG—CLIP/COLP (Calling/Connected Line Identification Presentation) and CNIP/
CONP (Calling/Connected Name Identification Presentation)
