Binatone 5 Telephone User Manual



Desk/Wall mount continue...
Insert the rigid clips of the stand into the slots
on the bottom of the phone (near the battery
cover). Press down firmly until the flexible
clips clicks into place.
To remove the stand, (1) pinch the flexible
clips, (2) pull back the stand, and then (3)
slide up and forward as shown below.
Mark two points on the wall that are 137mm
apart to lay the fixing centers as shown below.
BE CAREFUL to check that there are no
electrical wires hidden in the wall.
Fix two screws (supplied with the unit) at the
marked locations, leaving approximately 7mm
between the wall and the the screw head.
Hang the cradle unit on the screws using the
wall mount slots. You may need to remove the
telephone from the wall and tighten the
screws so that the cradle is securely fixed and
does not wobble. Place the Handset on the
cradle with the parking hook on the cradle
arranged to fit in the parking recess under the
earpiece on the Handset.
6
