2. Installation
4
1. Locating the Base unit
The Base unit should be placed on a level surface, in a position where:
the telephone line cable will reach your telephone line socket or
extension socket.
it is not close to a sink, bath or shower, or anywhere else where it
might get wet.
it is not close to other electrical equipment - fridges, washing
machines, microwave ovens, TVs, fluorescent lights, etc.
2. Plug the coiled handset cord into the Handset. Plug the other end into
the jack on the left side of the Base unit.
3. Place the Handset in the Base unit.
4. Plug the telephone line cord into the
PHONE LINE jack at the back of the
Base unit. Plug the other end
into a modular wall jack.
5. Lift the Handset and
check for Dial tone in
the earpiece.
Always use the telephone
line cord supplied with your
SpeakEasy 5. Other telephone
line cords may not work.
Installing Backup
batteries
1. Remove the Battery cover and insert
3 X 1.5V AA size alkaline batteries
(not included) into the battery
compartment paying attention to the
polarity marking as shown inside the
compartment.
2. Replace the battery cover until it
clicks into place.
Note: The Caller display will not work without batteries installed.
Warning: Disconnect the telephone
from the telephone line before
changing the batteries.
