12. Technical details
Standard Corded Telephone Caller Display with Speakerphone
Temperature range Operating 0 ºC to 40 ºC
Storage -20 ºC to 60 ºC
Port specification The port (connected to the telephone line) is a TNV3
port with respect to EN41003.
PBX compatibility Timed break recall: 98 ms. Pause length (using the
REDIAL/PAUSE button): 3.6 seconds. Signalling type:
DTMF (dual-tone multifrequency) also called tone
dialing.
Network connection This equipment is intended to be used in the UK only.
Operation on other countries’ PSTN termination points
cannot be guaranteed.
Declaration of conformity
The Binatone SpeakEasy 5 complies with the essential protective
requirements and objectives of:
EC Low Voltage Directive 73/23/EEC
EC EMC Directive 89/336/EEC
and conforms to the following relevant harmonized standards:
Safety: EN 60950
Other: I-CTR37, CTR38,
EN55-022, EN55024
Binatone operates a policy of continuous product improvement, and so
reserves the right to make changes to the product and functions without
notice.
Waste electrical products must not
be disposed of with household waste.
This equipment should be taken to
your local recycling centre for safe
treatment.
Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677
Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677
Binatone Help Line - 0845 345 9677
Calls are charged at Local Call rate.
