AT&T 6200 Cordless Telephone User Manual



INSTALLATION
To attach
To remove
Table/Desk Installation
3 Charge the handset battery.
Place the handset in the base for at least
24 hours the first time. After the first charge,
the battery is typically fully charged overnight.
4 Check for dial tone.
After the batteries are charged, pick up the
handset and press P; you should hear
a dial tone.
Standard
electrical outlet
Modular
telephone
jack
1 Connect the
telephone
line cord.
2 Connect the power cord.
b) Align two holes in
plug with socket
pins, and snap the
plug into place.
d) Replace cover by sliding
it up into place.
a) Remove battery
compartment
cover by pressing
on the
indentation
and sliding
downward.
c) Place battery pack in
compartment with the wires in
the lower left corner,along the
bottom of the battery pack.
Before You Install
1 Choose a location for the base near an electrical
outlet and a telephone jack.
This phone requires a modular telephone jack and a
standard electrical outlet (110v AC) not controlled by
a wall switch.
2 Install the handset battery following
Figure A below.
3 Attach the belt clip to the cordless handset
as in Figure B below (optional).
2
Figure A Figure B
