DSS/BLF LEDs ADD-ON CONSOLE LEDs
Telephone Status DSS/BLF Status CO Line Status LED Indication
Attendant message
Steady Green Idle Unlit
Idle Unlit Incoming call Rapid Flashing Red
In use Steady Red In use Steady Green
Hold Steady Red (by the attendant)
FWD All (DND)
Flashing Red Other-use Steady Red
Held call
- Your telephone Slow Flashing Green
- Other telephone Slow Flashing Red
1
General Information
The following should be considered when reviewing this user guide:
Attendant console keys can be assigned as Direct Station Selection/Busy
Lamp Field (DSS/BLF), Call Arrival or as additional central office lines
(CO Add-On Console.)
Refer to the Xen IPK Digital Telephone User Guide for additional
information on telephone operation.
All operational instructions assume Prime Line Pickup is assigned to
intercom dial tone, Ringing Line Preference is assigned, a Call
Appearance and Call Arrival key is assigned to all multiline telephones
and only a single tenant has been assigned in the system.
All access codes listed are standard; some may vary based on system
assignment.
Access to many features is based on system assignments. Not all features
may be available from your telephone.
The telephone display provides useful call processing information such
as trunk access, recall indication, feature confirmation, etc.
1. DSS keys (direct station
selection) or CO keys
(Central Office Lines)
2. Status Indicators
3. Dedicated Feature keys
1
2
3
