8
How to use
Summary of button functions
Function
HBM-520
Status
Action
Power on Power off Press the PWR button for 3 seconds.
Power off Power on Press the PWR button for at least
4 seconds.
Volume up Talking Briefly press the Volume Up button.
Volume down Talking Briefly press the Volume Down button.
Transferring a call Talking - Handset to Headset
Briefly press the CALL button on the
HBM-520(Headset and handset must
be paired)
- Headset to handset
Press and hold the VOLUME UP button
on the HBM-520 for 5 seconds.
Answering a call Ringing Briefly press the CALL button.
Ending a call Talking Briefly press the CALL button.
Call waiting Talking Press the CALL button for 1 second.
Last number redial Idle Press the CALL button for 1 second.
Voice dialing Idle Briefly press the CALL button.
(handset must support)
Manual pairing Power off
Press the
PWR
button for 5 seconds.
Call reject Ringing Press the
CALL
button for 1 second.
Multipoint
Call waiting*
- Answer a second call without hanging up the first call by pressing the
CALL button for 1second. Press the CALL button for 1second to
return to the original call.
- Briefly press the CALL button to terminate the active call or both calls
at once. (subject to handset's support)
Call Reject*
- Activate Call Reject by pressing the CALL button for 1second when
the handset rings.
* It is possible to use these functions only when your handset supports
them. For further information about using these features, please
consult your handset's user manual.
The LG HBM-520 is capable of having two handsets connected to the
Headset at the same time. This will give you the freedom of having only
one Headset to operate both your handsets.
Multipoint Connect
- Pair the Headset with one of your Bluetooth-enabled handsets.
(per the pairing instructions on pages 5-6).
- Turn off the Headset.
- With the power off, press and hold the PWR button on the HBM-520
for 5 seconds to enter Manual Pairing mode.
- Now, pair and connect the Headset with your other Bluetooth-enabled
handset. (This will be your Primary handset).
- Once this handset is paired and connected, go back and connect the
first paired handset to Headset. (This will be your Secondary handset).
* Note: When the HBM-520 is connected to two handsets at the same
time (Multipoint), the Headset calling functions will work with
the most recently used handset.
Calling Function
- Voice Dial and Last Number Redial features work with the Primary
handset. (most recently used handset).
- The first connected device is set as primary handset and the next
connected device is set as secondary handset.
- The device which made the last outgoing call will always be set as
the primary handset.
- To answer an incoming call on your secondary handset, while on a call
on your primary handset, hang-up the active-call (briefly press the CALL
button) and then answer the incoming-call (briefly press the CALL
button again).
9
How to use
Ear Loop Attachment and Removal
Attaching the ear loop
- Hold the ear loop just above the base (C shaped part), and snap it
into place behind the speaker on the HBM-520.
Removing the ear loop
- Hold the ear loop at the base (C shaped part), and pull, to unhook
the ear loop from the HBM-520.
Note: The ear loop can be attached to the HBM-520, as an option,
if necessary. Not every user will need to attach the ear loop.
