THIS EQUIPMENT IS NOT DESIGNED FOR MAKING
EMERGENCY TELEPHONE CALLS WHEN THE POWER
FAILS. ALTERNATIVE ARRANGEMENTS SHOULD BE
MADE FOR ACCESS TO DIAL EMERGENCY SERVICES.
Before operating this set,
please read these instructions carefully.
1 2
1 IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury, including the
1) Read and understand all the instructions.
2) Follow all warnings and instructions marked on the product.
3) Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4)
5) Do not overload wall outlets and extension cords as this can result in the
6) Unplug this product from the wall outlet and refer servicing to our Repair
• When the power supply cord or plug is damaged or frayed.
• If the product does not operate normally by following the operating instructions.
• If the product has been dropped and the cabinet has been damaged.
•
If the product exhibits a distinct change in performance.
7) NEVER use your phone outdoors during a thunderstorm-unplug the
8) Do not use the telephone to report a gas leak in the vicinity of the leak.
9) Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation
periods for the handsets are only applicable with the default battery capacities
10) The use of other battery types or non-rechargeable batteries/primary cells
can be dangerous. These may cause interference and/or damage to the unit
or surroundings. The manufacturer will not be held liable for damage arising
from such non-compliance.
11) Do not use third party charging bays. Damage may be caused to the batteries.
12) Please ensure the batteries are inserted in the correct polarity.
13) Dispose of batteries safely. Do not immerse them in water, burn them, or put
Package contents
The package contains the following items:
• 1 Handset
• 1 Base station
• 1 Mains power adapter
• 1 Telephone line cord
• 2 AAA rechargeable batteries
• 1 User manual
them where they could get punctured.
Centre under the
following conditions:
following:
a bath tub, kitchen sink, swimming pool).
Keep your phone away from hot, humid conditions or strong sunlight,
and don't let it get wet or use this product near water (for example, near
base from the telephone line and the mains socket when there are storms
in your area. Damage caused by l ightning is not covered by the guarantee.
Note: If you have a Twin, Triple or Quad system, you will also have the requisite
extra handset(s) and batteries, and a charger pod for each extra handset.
risk of fire or electric shock.
3 4
Connection and conditions for use:
You can connect your phone to a direct exchange line (DEL) on a local
exchange with its own phone number; to an extension socket connected to a DEL;
or to an extension on an approved compatible PBX. Do not connect as an
extension to a payphone.
The ringer equivalence numbers (REN) of all equipment (phones, fax machines,
modems, etc.) connected to an exchange line must not add up to more than 4,
otherwise one or more of them may not ring and/or answer calls correctly. The
marked otherwise.
phone has a REN of 1, and most other telephones have a REN of 1 unless
Handset - Base Connection
1) When purchased, all handsets are already registered to the base unit and should
link to it when they are all powered up.
2) To use your cordless handset and base unit together, you must be able to
establish a radio link between them. The signal between the handset and the base is
> Any large metal object, such as a refrigerator, mirror or filing cabinet, between the
handset and the base unit may block the radio signal.
> Other solid structures, like walls, may reduce the signal strength.
> Other electrical equipment may cause interference and/or affect the range.
3) Do not place close to another telephone, a TV or audio equipment - it may cause
interference.
4) Out of Range warning. If you hear a warning tone during a call, and/or the sound
in the earpiece becomes faint or distorted, you may be going out of range of the base
unit, so move nearer to the base unit within 20 seconds, otherwise the call may be
cut off.
to 300 metres outdoors or 50 metres indoors. Be aware that:
in accordance with the normal standards for a DECT phone: Maximum range up
6
5
2 INSTALLING YOUR PHONE
2.1 Connecting the base station
1) Plug the power supply
and line cord
into
2) Plug the power adapter into a 230Vac,
3) Always use the cables provided in the box
Warning: Use only the provided adaptor, using
other power supplies may cause a hazard.
the base station.
50Hz mains socket, and the line cord into your
2.2 Installing and charging the batteries
1) Place the 2 supplied batteries into the battery
3) Put the handset on the base and charge for
15 hours before using the handset for the first time.
If you have a Broadband line
If you connect your telephone to a line with
insert a micro-filter between the telephone
and the telephone line, otherwise you may get
interference between the telephone and the broadband,
which could cause problems.
a broadband connection, you will need to
telephone line socket.
Warning: Install the base unit in a position where the mains adapter plug
will reach an easily accessible mains socket. Never try to lengthen the
mains power cable.
Note: The base unit needs mains power for normal operation, not just for
charging the handset batteries.
Use only the NiMH rechargeable battery type
The handset will give a beep when it is properly placed on the base or charger.
In a home with broadband, every telephone must have a micro-filter connected,
not just the one at the telephone point that your modem is connected to.
If you need more broadband micro-filters, contact your broadband supplier.
2) Position the battery compartment cover over the
batteries and slide up to click into place.
provided.
compartment with the polarity markings as shown.
3 GETTING TO KNOW YOUR PHONE
3.1 Handset Overview
The LCD display gives you information on the current status of the telephone.
Indicates you can scroll up / down the menu items / Phonebook list /
Steady when the handset is in range of the base. Flashes when out of
Steady when an intercom call is in progress.
Flashes when there is an incoming internal call.
Indicates a call is in progress on that handset.
range of the base or not registered to the base.
Indicates that your answering machine (TAM) is on and flashes when
there is a new message.
3.3 Display Icons and Symbols
7 8
3.2 Base Station with Telephone Answering Machine (TAM) Control
Redial list / Call List
Steady when an alarm is set. Flashes when the alarm is sounding.
Indicates that the keypad is locked.
Indicates when you have a new Voice Mail message.
(This is a Caller Display service and is not usually available from
UK network providers.)
Indicates when the battery is fully charged.
Whole icon flashes when the battery is charging.
Internal block icon flashes when the battery is in final charging stage.
Indicates when the battery needs charging.
Flashes when low battery power level is detected.
(BACK)
(INT)
Indicates when there are more characters or numbers in front of those
Indicates when there are more characters or numbers after those being
LEFT SOFT KEY function. Press to access the main menu.
LEFT SOFT KEY function. Press to confirm the current selection.
Indicates a new TAM message is playing or a new Call List entry is being
RIGHT SOFT KEY function. Press to start an intercom call.
RIGHT SOFT KEY function. Press to go back to the previous menu level
RIGHT SOFT KEY function. Press to clear a character, stop the alarm, or
being displayed.
displayed.
or cancel the current action.
mute/unmute the microphone during a call.
displayed.
Indicates that the
3.4 Menu Structure
In idle mode, press <MENU/OK> to go to CALL LIST, the first option in the
Refer to the following for the menu structure.
Press <UP> or <DOWN> to go to other options in the menu list.
Press <MENU / OK> to enter a sub-menu or function.
Press <C / MUTE> to go back to the previous level.
9 10
menu list.
4 USING YOUR PHONE
4.1 Make a Call
4.1.1 Preparatory Dialling
Enter the phone number and press <TALK ON> to connect to the line and
dial the number. When entering the number, if you make a mistake, press
4.1.2 Direct Dialling
Press <TALK ON> to connect to the line and then enter the phone number.
4.1.3 Call from the phonebook
Press <MENU/OK>, <DOWN> and then <MENU/OK> again to access the
Press <TALK ON> to dial out the selected phonebook entry.
(Note: if you enter a wrong digit you cannot correct it with the <C/MUTE> key.)
phonebook and press <UP/DOWN> to select the desired phonebook entry.
4.1.4 Call from the Call List (only available with Caller Display)
Press <UP> to access the Call List and press <UP/DOWN> to select the desired
Press <TALK ON> to dial out the selected Call List entry.
Note: You can also access the Call List by pressing <MENU/OK> twice.
4.1.5 Call from the redial list
Press <REDIAL> to access the redial list and press <UP/DOWN> to select the
Note: The alphanumeric keys provide a short-cut to find entries beginning with
the corresponding letters.
Call List entry.
desired redial number.
Press <TALK ON> to dial out the selected redial number.
4.1.6 Call timer
Your handset automatically times the duration of every call.
The call timer is displayed as soon as you answer a call or 15 seconds after
It is shown in hours, minutes and seconds format (HH:MM:SS).
4.2 Answer a Call
If the handset is not on the charging cradle:
When the phone rings, press <TALK ON> to answer a call.
Note: If AUTO ANSWER is set to ON, then lifting the handset off the base or
charger will answer the call automatically, and no buttons need to be
4.3 End a Call
During a call press <TALK OFF> to end the call.
OR
Put the handset on the base station or charger to end the call.
pressed.
4.4 Adjust Volume
There are 5 levels (VOLUME 1 to VOLUME 5) to choose from for the earpiece
During a call:
setting is shown.
When you end the call, the setting will remain at the last selected level.
4.5 Mute a Call
You can talk to someone nearby without letting the caller hear you during a call.
During a call:
Press <C/MUTE> to mute the microphone and “MUTED” will display on the LCD.
Your caller cannot hear you. Press <C/MUTE> again to unmute the microphone.
4.6
the
In idle, press and hold <HASH/#> to turn off the handset ringer. The “RINGER
OFF”
volume.
icon is displayed on the LCD.
4.7 Turn on the Keypad Lock
In idle, press and hold <STAR/*> to turn on the keypad lock, and the "KEY
4.8 Redial the last number
You can redial any of the 5 last numbers called. If you have stored a name
number, the name will be displayed instead.
4.8.1 Redial a Number from the Redial List
1. Press <REDIAL> to access the redial list.
Note: If the redial list entry shows a name, press <Hash/#> to view the number
2. Press <UP/DOWN> to browse the redial list.
3. Press <TALK ON> to dial to the selected redial number.
Note: If there are no numbers in the redial list, the display shows
“
EMPTY
”
.
Note: The display will still flash the Call icon and show CALL or the Caller Display
number, when there is an incoming call, even if the ringer is turned off
To turn the ringer back on, press and hold <HASH/#> again.
Note: You can still use <TALK ON> to answer a call
To turn the keypad lock off, press and hold <STAR/*> again.
The most recent last number will display at the top of the redial list.
of this entry.
handset is ringing.
when the
dialling and remains on the screen for 5 seconds after the end of the call.
ress <UP/DOWN> to select volume 1-5. The current
Turn off
Handset Ringer
P
11 12
in phonebook to go with the
4.8.2 Store a Redial Number into the Phonebook
1. Follow Steps 1 and 2 in section 4.8.1.
2. Press <MENU/OK> to show ADD TO PB.
3. Press <MENU/OK> and then enter the name you want to use in the
phonebook.
4. Press <MENU/OK> and then modify the number, if necessary.
5. Press <MENU/OK> to show <MELODY 1>.
6. Press <UP/DOWN> to browse the ringtone list. The respective ringtone will
be played when browsing the ringtone list. (Note: the selected melody will
7. Press <MENU/OK> to confirm, and the entry will be stored.
only be played if you subscribe to Caller Display and the incoming number
matches the stored number.)
4.8.3 Delete a Redial Number
1. Follow Steps 1 and 2 in section 4.8.1.
2. Press <MENU/OK> and <UP/DOWN> to select DELETE.
3. Press <MENU/OK> to confirm, and the entry will be deleted.
4.9 Find the Handset
You can locate the handset by pressing <FIND> on the base station. All the
handsets registered to the base will produce the paging tone and show
4.8.4
Delete all Redial List entries
1. Follow Steps 1 and 2 in section 4.8.1.
2. Press <MENU/OK> and <UP/DOWN> to select DELETE ALL
3. Press <MENU/OK> to display <CONFIRM?>.
4. Press <MENU/OK> to confirm. All entries will be deleted and the display
<TALK OFF> /<C/MUTE> on any handset or <FIND> on the base again.
Note: If there is an incoming call during paging, the phone will ring with the
4.10 Make an Internal Call (
This feature is only applicable when there are at least two registered handsets.
It allows you to make internal calls, transfer external calls from one handset to
incoming call instead of paging.
"PAGING" on the display. You can stop the paging by pressing <TALKON>/
another handset and make conference calls. If the called handset is not
answered within 60 seconds, the called handset will stop ringing and the calling
Note: If only one handset is registered to the base station, when <C/MUTE>
is pressed, it will display “NOT POSSIBLE”
4.10.1 Intercom Another Handset
1. In idle mode, press <C/MUTE> and all the other registered handset
2. Enter the number of the handset that you want to call, or press the < 9 >
3. The called handset rings and <TALK ON> must be pressed on that handset
Note: If only two handsets are registered to the base station, pressing
<C/MUTE> will call the other handset immediately.
numbers will display, along with a "9".
4.10.3 Transfer an External Call to another handset
During an external call:
1. Press <MENU/OK> to show INTERCOM
.
2. Press <MENU/OK> to show all the other registered handset numbers,
plus "9".
3. The external call is put on hold automatically and the called handset rings.
4. Press <TALK ON> on the called handset to establish an internal call.
Enter the number for the handset you want to transfer the call to.
handset will return to
standby mode.
key to call all handsets.
5. Press <TALK OFF> on the calling handset or put the calling handset on the
charging cradle to end the current call with the external party.
6. The external call is transferred to the called handset.
4.10.2 Call All Handsets
1. In idle mode, press <C/MUTE> and the registered handsets will display.
2. Press the < 9 > key to ring to all registered handsets
4.10.4 Make a 3-way Conference Call
The conference call feature allows one external call to be shared with two
handsets (in intercom).
The three parties can share the conversation and no additional network
subscription is required.
During an external call:
1.
Follow Steps 1 to 4 in section 4.10.3.
2. Press and hold <STAR / * > on the calling handset to establish the conference
call.
Either handset can exit the conference by pressing <TALK OFF>, leaving
to establish the intercom call.
Note: If there is an external call while you are on an intercom call, you'll
hear warning beeps, and you have to end the intercom call, before you can
answer the external call.
Note: If the other handset has not answered the intercom call, you can stop
the intercom and return to the external call by pressing <TALK OFF>
13 14
Multi - handset versions only)
5 PRIVATE PHONEBOOK
Each handset can store up to 20 private phonebook entries with names and
numbers. Each phonebook entry can have a maximum of 20 digits for the
phone number and 12 characters for the name. You can also select different
ringtones for your phonebook entries. (Note: the different ringtones only play if
5.1 Add a New Phonebook Entry
In idle:
1. Press <MENU/OK> and <UP/DOWN> to select
PHONEBOOK and then
2. Press <MENU/OK> to show ADD.
Press <MENU/OK> and then enter the name.
4. Press <MENU/OK> and then enter the number.
5. Press <MENU/OK> and <UP/DOWN> to select the desired ringtone for
6. Press <MENU/OK> to store the phonebook entry.
you subscribe to Caller Display and the incoming number matches the stored
number.) Phonebook entries are stored alphabetically by name.
5.2 Search a Phonebook Entry
In idle:
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2. Enter the first letter of the name using the alphanumeric keys(e.g. if it
5.3 View a Phonebook Entry
In idle:
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2. Press <UP/DOWN> to select the desired phonebook entry.
3. Press <MENU/OK> and <UP/DOWN> to select VIEW.
4. Press <MENU/OK> and <UP/DOWN> to review the name, number and
Note: If the number is more than 12 digits, press <LEFT SOFT KEY> or
<RIGHT SOFT KEY> to view the remaining digits.
to scroll to the entry you want.
begins with C, press the 2 key three times), and then <UP/DOWN>
Remote operation
Using a tone-dialling phone, dial your home number
You can also use the codes on the other side of this card
While your outgoing message is playing, press
Key in your remote security code
The default code is 0000. For details of how to set a new code,
see the User Guide
8.5.9.1 on page 30.
1
2
3
4
Note: <*> key must be entered while the OGM is still playing, and the 4-digit
consecutively, the line will be release
Note: If your answering machine is switched off, the phone will enter into
the remote access mode after 14 rings.
You can then enter the 4-digit remote access PIN
(Default Remote Access PIN is 0000) to activate the remote access feature.
The
PIN should follow without any delays. If the 4-digit Remote Access
PIN is entered incorrectly three times
automatically.
15 16
press <MENU/OK> to access the phonebook.
press <MENU/OK> to access the phonebook.
3.5 Text and Digit Entry Table
The following table shows you where each letter and punctuation character can
be found, by using repeated presses of the alphanumeric keypad. This will be
helpful when storing a name in the phonebook and renaming your handset.
In editing mode, a cursor is displayed to indicate the current text entry position.
It is positioned at the right of the last character entered.
Writing Tips:
1. Once a character is selected, the cursor will move to the next position after
2. You can move the cursor within the text with the <UP/DOWN> keys to
amend the text entry.
3. Press <C/MUTE> to delete the last character.
4. Press and hold <C/MUTE> to delete the entire text string.
3.5.1 Character Set
Key
Press
1st 2
nd
3rd 4th 5th 6th 7th 8th 9th 10th
1 space - 1 1
2 A B C 2 2
3
D E F 3 3
4 G H I 4 4
5 J K L 5 5
6 M N O 6 6
7 P Q R S 7 7
8 T U V 8 8
9 W X Y Z 9 9
0 0 0,or P (Pause) if press and hold
*
*
? / \
( ) *
# o
,
- #
Alphanumeric Editing
(For phonebook name editing and renaming handset )
Number Editing (For phone
number editing,date/time editing)
ADD TO PB
DELETE
DELETE ALL
DETAILS
Shows EMPTY
or the
first Call
List Entry. Then
<OK> for:
,
,
&
Main
Menu
CALL LIST
PHONEBOOK
BS
SETTINGS
HS
SETTIN
GS
REGISTRATION
DEFAULT
ANS. MACHINE
Sub
menu
PIN? - - - -
MSG PLAYBACK
DELETE ALL
MEMO
TAM ON/OFF
TAM SETTINGS
ANSWER MODE
TAM LANGUAGE
OGM SETTINGS
ANSWER DELAY
RECORD TIME
REMOTE ACC
COMPRESSION
PIN? - - - -
<UP/DOWN>
Key Press
<MENU>
<UP/
DOWN>
<UP/
DOWN>
<UP/
DOWN>
<UP/
DOWN>
<UP/
DOWN>
<UP/
DOWN>
phonebook Entry.
ADD
VIEW
EDIT
DELETE
DELETE ALL
PB STATUS
Shows EMPTY
or the
first
Then
<OK> for:
ADD
PB STATUS
or
DIAL MODE
FLASH TIME
CHANGE PIN
ALARM
RING SETUP
TONE SETUP
LANGUAGE
RENAME HS
HS DISPLAY
AUTO ANSWER
DATE & TIME
BS RINGER
RING VOLUME
DELETE HS
CHANGE PIN
BS SCREENING
Note: There are some different characters if the handset language is
changed (7.3.5).
a short pause.
5.4 Edit a Phonebook Entry
In idle:
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2. Press <UP/DOWN> to select the desired phonebook entry.
3. Press <MENU/OK> and <UP/DOWN> to select EDIT.
4. Press <MENU/OK> to display the current name.
5. Edit the name and press <MENU/OK>.
6. Edit the number and press <MENU/OK>.
7. Press <UP/DOWN> to select the ringtone and press <MENU/OK> to confirm.
5.5 Delete a Phonebook Entry
In idle:
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2. Press <UP/DOWN> to select the desired phonebook entry.
3. Press <MENU/OK> and <UP/DOWN> to select DELETE.
4. Press <MENU/OK> to confirm, and the entry will be deleted.
5.6 Delete
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2.
3.
Press <MENU/OK> and <UP/DOWN> to select DELETE ALL.
4.
Press <MENU/OK> to display <CONFIRM?>.
Press <MENU/OK> to confirm. All entries will be deleted and the display will
5.7 Check the Phonebook Usage
You can check how many phonebook entries are stored in your handset and
how many phonebook entries are available for you to store in the phonebook.
1. Press <MENU/OK> and <UP/DOWN> to select PHONEBOOK and then
2. Press <MENU/OK> and <UP/DOWN> to select PB STATUS.
3. Press <MENU/OK> to display how much of the phonebook is being used
for example <14/20 USED> means 14 entries are stored out of the
total 20 available spaces.
all Phonebook entries
press <MENU/OK> to access the phonebook.
press <MENU/OK> to access the phonebook.
press <MENU/OK> to access the phonebook.
press <MENU/OK> to access the phonebook.
TABLE OF CONTENTS
1
IMPORTANT SAFETY INSTRUCTIONS
...........................................................
2
INSTALLING YOUR PHONE
............................................................................5
2.1
CONNECTING THE BASE STATION
..........................................................................5
2.2 ......................................................5
3
GETTING TO KNOW YOUR PHONE
................................................................6
3.1
HANDSET OVERVIEW
................................................................................................6
3.2
BASE STATION WITH TELEPHONE ANSWERING MACHINE (TAM) CONTROL
......
3.3
DISPLAY ICONS AND SYMBOLS
...............................................................................7
3.
MENU STRUCTURE
....................................................................................................
3.
TEXT AND DIGIT ENTRY TABLE
................................................................................9
3.5.1
9
4
USING YOUR PHONE
.....................................................................................
4.1
MAKE A CALL
............................................................................................................
4.1.1 P
REPARATORY DIALLING
.....................................................................................
4.1.2
DIRECT DIALLING
...................................................................................................
4.1.3 .............................................................................10
4.1.4 CALL FROM THE CALL LIST(ONLY AVAILABLE WITH CALLER DISPLAY)
4.1.5
CALL FROM THE REDIAL LIST
4.1.6
.............................................................................................................10
4.2
ANSWER A CALL
.....................................................................................................
4.3
END A CALL
..............................................................................................................
4.4
ADJUST EARPIECE VOLUME
...................................................................................
4.5
MUTE A CALL
............................................................................................................
4.6
11
4.7
TURN ON THE KEYPAD LOCK
................................................................................
4.8
...................................................................................
4.8.1
REDIAL A NUMBER FROM THE REDIAL LIST
.......................................................
4.8.2
STORE A REDIAL NUMBER INTO THE PHONEBOOK
..........................................
4.8.3
DELETE A REDIAL NUMBER
..................................................................................
4.8.4 DELETE ALL REDIAL LIST ENTRIES
4.9
FIND THE HANDSET
.................................................................................................
4.10
MAKE AN INTERNAL CALL(FOR MULTI-HANDSET VERSIONS ONLY )
...............
4.10.1
INTERCOM ANOTHER HANDSET
.........................................................................
4.10.2
CALL ALL HANDSETS
............................................................................................
4.10.3
TRANSFER AN EXTERNAL CALL TO ANOTHER HANDSET.
...............................
4.10.4
MAKE A 3-WAY CONFERENCE CALL
...................................................................
5
PRIVATE PHONEBOOK..................................................................................
5.3
VIEW A PHONEBOOK ENTRY
.................................................................................
5.1
ADD A NEW PHONEBOOK ENTRY
..........................................................................
5.2
SEARCH A PHONEBOOK ENTRY
............................................................................
4
5
8
10
10
10
10
CHARACTER SET
10
TURN OFF HANDSET RINGER
3
10
.........
...............................................................................10
11
11
11
.................................................................................
11
11
......................................................................
11
12
12
12
12
13
13
13
13
14
14
14
14
5.4 E
DIT A
P
HONEBOOK
E
NTRY
...................................................................................
5.5
D
ELETE A
P
HONEBOOK
E
NTRY
.............................................................................
5.6 D
ELETE
5.7
C
HECK THE
P
HONEBOOK
U
SAGE
.........................................................................
6
CALLER DISPLAY (NETWORK DEPENDENT)
..............................................
6.1
VIEW THE CALL LIST
................................................................................................
6.2
STORE A CALL LIST NUMBER INTO THE PHONEBOOK
......................................
6.3
DELETE AN ENTRY IN THE CALL LIST
...................................................................
6.4 DELETE ALL CALL LIST ENTRIES
7
PHONE SETTINGS
.........................................................................................
7.1
DATE AND TIME SETTINGS
......................................................................................
7.1.1
CHANGE THE DATE FORMAT
.................................................................................
7.1.2
HANGE THE TIME FORMAT
....................................................................................
7.1.3
SET THE TIME
..........................................................................................................
7.1.4
SET THE DATE
.........................................................................................................
7.2
ALARM SETTINGS
....................................................................................................
7.2.1
TURN ON/OFF THE ALARM
....................................................................................19
7.2.2
SET THE ALARM TIME
............................................................................................ 19
7.3
HANDSET SETTINGS
................................................................................................
7.3.1
SET THE RINGER MELODY FOR INTERNAL CALLS
7.3.2
SET THE RINGER MELODY FOR EXTERNAL CALLS
...........................................
7.3.3
SET THE RINGER VOLUME
....................................................................................
7.3.4
SET ALERT TONES
..................................................................................................
7.3.5
SET THE HANDSET LANGUAGE
............................................................................
7.3.6
RENAME THE HANDSET
.........................................................................................
7.3.7
CHOOSE THE INFORMATION TO BE DISPLAYED IN IDLE
..................................
7.3.8
SET THE AUTO ANSWER
.......................................................................................
7.4
BASE SETTINGS
........................................................................................................21
20
2
TROUBLESHOOTING
...............................................................................................
DECLARATION OF CONFORMITY
........................................................................
20
20
21
21
7.4. DE-REGISTER A HANDSET
....................................................................................21
7.4. CHANGE THE DIAL MODE
......................................................................................
7.4. CHANGE THE FLASH (RECALL)TIME
....................................................................
7.4. CHANGE THE SYSTEM PIN CODE ........................................................................
22
7.5
REGISTRATION .........................................................................................................23
7.6
RESET YOUR PHONE ...............................................................................................
22
22
1
2
3
4
9
ALL PHONEBOOK ENTRIES
15
11 GUARANTEE AND SERVICE
.................................................................................
24
8
ANSWERING MACHINE
.......................................................... 24
10
32
33
34
....................................................................................
Remote
..
Card .............
..................................................................................................
Remote Card
29
16
15
15
15
.....................................................................
17
18
17
17
17
.........................................................................
18
............................................
18
18
18
18
19
20
20
23
................................................................................
21
INSTALLING AND CHARGING THE BATTERIES
7
....................................................................................................
CALL FROM THE PHONEBOOK
CALL TIMER
REDIAL THE LAST NUMBER
19
1
12
8.1 TURN ON/OFF THE ANSWERING MACHINE
248.2 L
258.3
268.4
......................................................................... 268.5 ANSWERING MACHINE SETTINGS
ISTEN TO THE MESSAGES IN THE ANSWERING MACHINE ..............................
DELETE ALL MESSAGES IN THE ANSWERING MACHINE ...................................
RECORD MEMO ........................................................................................................
d
Press
approximately 60
TAM ON/OFF
Press to turn on the answering
Press again to turn off
PLAY/STOP
Press to play the message
Press to stop the message
SKIP FORWARD
Press to skip the current
machine.
message and play the next
message.
to
It will ring for
MESSAGE LED
Light On when TAM is ON
Light Off when TAM is OFF
the answering machine.
seconds
Flashes when new
messages received
or incoming call.
DELETE
SKIP BACKWARD
Press to repeat playing
Press twice to skip back
to the previous message.
playback
From idle: Press and hold
to delete all the old messages.
Press once to delete
t
he message during playback
the current message from
the beginning.
Veva 1520 system
Press to
decrease the playback
Volume, or the base ringer
volume during incoming
ringing.
FIND
find your handset.
2 LEFT SOFT KEY( )
Use with icons on display above, to
open menu and confirm options.
Make or answer calls
4 DOWN( )
From idle: access the Redial List
In lists: move down the options
During calls / ringing: decrease the
5 REDIAL( )
Use with icons on display above, to
8 R - RECALL( )
Sends a recall (R) signal, used for some PBX / Calling Features.
7 TALK OFF( )
End a call or return to previous menu.
1 UP ( )
From idle: access the Call List
Press and hold to turn the handset on / off.
In lists: move up the options
During calls / ringing: increase the volume.
menu, mute the microphone or make
3 TALK ON( )
(CLEAR/BACK/MUTE/INTERCOM)
6 RIGHT SOFT KEY( )
clear characters, go back to previous
an intercom call.
volume
3
1
2
4
5
8
6
7
also called Flash
Press to
increase the playback
Volume, or the base
during incoming ringing.
ringer volume
Digital Cordless Telephone
with Answer Machine
Veva 1520
Veva 1520 Twin
Veva 1520 Triple
Binatone Helpline (for UK only)
Monday to Friday from 9:00am to 5:00pm
Tel: 0845 345 9677
**Please note that all calls are charged at local rate
Or visit our website: www.binatonetelecom.com
USER GUIDE
Veva 1520 Quad
Charger unit:
TenPao - S004LB0600030 / S004LV0600030 -
input 100-240VAC 50/60Hz 150mA, output 6VDC 300mA
Salcomp – VT1001 / VT1000 .
Base unit:
TenPao - S004LB0600045 / S004LV0600045 -
input 100-240VAC 50/60Hz 150mA, output 6VDC 450mA
Salcomp – VT0601 / VT0600 .
Battery information as below:
GPI – VTHC043C00, Type NiMH (Rechargeable battery)
BYD- H-AAA400A, Type NiMH (Rechargeable battery)
CORUN- NI-MHAAAJ400, Type NiMH (Rechargeable battery)
Electrical power
input 100-240VAC 50/60Hz 150mA, output 6VDC 300mA
input 100-240VAC 50/60Hz 150mA, output 6VDC 450mA
Voltage Rating
400mAh ,2 X 1.2V AAA Size
Voltage Rating
400mAh , 2 X 1.2V AAA Size
Voltage Rating
400mAh, 2 X 1.2V AAA Size
TECHNICAL DETAILS
Standard
Frequency range
Channel bandwidth
Operating range
Operating time
Temperature range
Digital Enhanced Cordless
Telecommunication(DECT)
1.88 to 1.9GHz
1.728 MHz
Up to 300m outdoors;
Standby: 100 hours,
Talking:
10 hours
Battery charge time:15 hours
Operating 0 Cto 40 C,
Storage -20 Cto 60 C
(bandwidth =20 MHz)
Up to 50mindoors
Caution
Risk of explosion if battery is replaced by an incorrect type
Dispose of used batteries according to the instructions.
The port (connected to the mains power supply) is a SELV port with
The port (connected to the telephoneline ) is a TNV port with
respect to EN41003.
CLEANING AND CARE
Do not clean any part of your phone system with benzene, thinners or other
solvent chemicals as this may cause permanent damage which is not covered
by the Guarantee.
When necessary, clean it with a damp cloth.
Keep your
hot, humid conditions
or
strong sunlight, and don't let it get wet.
Every effort has been made to ensure high standards of reliability for your
consult your supplier or the Helpline.
do
not try to repair it yourself
phone system away from
Port specification
respect to EN41003.
phone system. However, if something does go wrong, please
handset ringer is switched off.
<C/MUTE> to delete digits.
show <EMPTY>.
press <MENU/OK> to access the phonebook.
will show <EMPTY>.
LOCK" icon is displayed on the LCD.
the other handset still connected to the external call.
your phonebook entry.
ringtone of the selected phonebook entry.
3.
